MALÅ · SKU IS-MALA-GD600
GPR system: MALÅ GeoDrone 600
Airborne GPR purpose-built for drones, using Guideline Geo's latest GPR HDR technology.
Price on request
Airborne GPR system engineered specifically for drone deployment, built around Guideline Geo's latest GPR HDR technology and sized for the DJI M400 and M350/M300 RTK.
The GeoDrone 600 has a built-in data logger and a GNSS antenna port; a basic GNSS antenna ships in the kit, but a higher-quality helical antenna is recommended for better positioning accuracy.
Utility searchUnderground infrastructure mappingArchaeologyGeotechnical surveysGeological stratigraphyGlaciology, snow/ice thickness profiling
Technical
| Type | Single-channel with shielded antenna |
| Central Frequency | 600 MHz |
| Operating Bandwidth | 250-900 MHz |
| Sampling | Real Time Sampling (RTS), MALÅ HDR |
| Depth | Up to 4 m in average soil |
| Data | MALÅ proprietary format |
Environmental
| Temperature | -20°C to 50°C |
| Ingress Protection | IP65 |
Mechanical
| Size | 620 x 216 x 80 mm |
| Weight | 2.7 kg in operation |
What's in the kit
- MALÅ GeoDrone 600 antenna + smart battery
- GNSS antenna ANN-MS - 700mm
- Smart Battery 10.8V (RRC2040)
- Dual Li-ion battery charger
- Payload Mounting Kit
- MALÅ Controller App
- Hard case
